0.1um 10" Pharmaceutical PES Filter Cartridge Asymmetric Pore Structure

Name: 01um 10quot Pharmaceutical PES Filter Cartridge Asymmetric Pore Structure
Brand: PULLNER
Price: 1 USD

Buy cheap 0.1um 10" Pharmaceutical PES Filter Cartridge Asymmetric Pore Structure product

Brand Name : PULLNER

Model Number : PES

Certification : FDA, ISO

Place of Origin : Shanghai China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 100 pieces per week

Delivery Time : 12 working days

Packaging Details : Vacuum packing; 50pcs per carton.

OD : 2.7" (69mm)

Filter media : PES

Filtration rating : 0.1um, 0.22um, 0.45um, 0.65um

Length : 10"

Product name : PES Filter Cartridge

Filter Medium : Double Layer PES Membrane

Support Layer : Polypropylene

Effective Filter Area : 1.28 ㎡

Maximum Temperature : 90℃

Max. Differential Pressure : 4.0 Bar / 21℃

Steam Sterilization : 121℃ / 30min

Inline Steam Sterilization : 121℃ / 30min

Hot Water Sterilization : 85℃ / 30min

Contact Now

Beverage and Pharmaceutical High Flow PES Filter Cartridge 10" Length Long Service Life

General Description

The HFPS series filter cartridge is modified high-throughput sterilization filter, made of unique anti-contamination asymmetric Polyethersulfone(PES) membrane. The asymmetric membrane pore structure provides high throughput. Its high throughput makes them extremely dirt holding capacity and longer service life.

Applications

Large infusion sterilization filtration
Eye drop sterilization filtration
Biological vaccine, blood product filtration
Buffer, culture solution sterilization filtration
Water-based antibiotic liquid filtration

Features and Benefits

High throughput, long service life;
Asymmetric membrane pore structure gradient pore size greatly improves dirt holding capacity;
Integrity test ensures absolute sterilization;
Wide range of chemical compatibility, pH working range 1-14;
No any adhesives and surfactants, effectively reducing the risk of precipitation.

Material construction and Technical parameters

Filter media	Asymmetric Polyethersulfone(PES) membrane.
Support/Drainage	PP
Center core/outer support/end caps	PP
Max. operating temperature	90°C
Max. operating different pressure:	4.0 bar / 21°C 2.4 bar / 80°C
Max. operating different pressure: (reverse direction)	2.0 bar/21℃
Steam sterilization	121℃/30min
Filtration area	0.6-0.7㎡/10’’
Biosecurity	Each 10’’Dissolution＜30mg Endotoxin＜0.25EU/ml
