Replace Park Cartridge Filter 40" PP Pleated Filter Cartridge

Name: Replace Park Cartridge Filter 40quot PP Pleated Filter Cartridge
Brand: PULLNER
Price: 1 USD

Buy cheap Replace Park Cartridge Filter 40" PP Pleated Filter Cartridge product

Brand Name : PULLNER

Model Number : PHFK

Certification : FDA

Place of Origin : Shanghai China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal

Supply Ability : 800pcs per week

Delivery Time : 3-7days

Packaging Details : Carton box after poly bag. 4pcs per carton

PHFK : High Flow Filter Cartridge

Maximum Operating Temperature : 82℃

Filtration micron : 1um, 2um, 5um, 10um, 15um, 20um, 30um, 50um, 70um, 100um

Filter area : 6.6㎡

Length : 40"(1016mm)

Flow rate : 35m³/hr

Maximum Operating Differential Pressure : 3.5bar@21℃

Filtration Efficiency : Beta 5000

Material : PP

OD : 6" (152.4mm)

Contact Now

CPP/CPU Filter Element OD 6" Absolute 1um 99.8% efficiency PP Pleated High Flow Filter Cartridge

General information
PHFK series high flow filter cartridge is made of 6" (152.4mm) diameter, material: PP, Organic fiber and Glass fiber, end caps material use glassfiber reinforced PP. Bigger diameter provide bigger filtration area, high flow rate, high dirt holding capacity and longer use life.

Material Construction

Filter Media	PP: Deep Pleated PP/Melt PP	FO: Organic Fiber	GF: Resin Synthetic Glass Fiber
Support/Drainage	PP	Organic Fiber	Polyester
End Cap Material	Fiberglass Reinforced Polypropylene	Fiberglass Reinforced Polypropylene	Fiberglass Reinforced Polypropylene

Flow Rate and Filtration Area

Size (Diameter*Length)	Design Flow (m³/hr)	Maximum Flow (m³/hr)	Filtration Area (㎡)
6"*20"	15	40	2.6
6"*40"	30	80	5.2
6"*60"	45	120	7.8

Filter Performance

Micron	1um, 3um, 5um, 10um, 15um, 20um, 50um, 70um, 100um
Max. operating temperature	82℃
Max. operating differential pressure	3.44bar@82℃
Suggestion pressure for filter replacement	2.5Bar@20℃

Performance comparison
Comparison chart of specific filter element number and corresponding filter footprint.
